Product Overview
WF·EL TNS-N-30KVA is a new generation three-phase intelligent separate phase high-precision fully automatic AC voltage regulator, specially designed for 380V/50Hz industrial power grid with serious three-phase unbalance problem.
It adopts advanced three-phase separate independent digital voltage regulation technology, each phase voltage is monitored and adjusted independently, which has extremely strong ability to adapt to unbalanced grid voltage. Equipped with high-definition LCD display to real-time monitor A/B/C three-phase voltage, current and operating status, automatically compensate grid voltage fluctuation. With full copper winding coil, low power loss, high efficiency ≥98%, complete intelligent safety protection system, it supports 7×24 hours continuous industrial operation, effectively protecting CNC machine tools, laser cutting machines, injection molding machines and other industrial equipment from unstable power supply damage.
Core Advantages
- Three-phase separate independent voltage regulation: Perfectly solve serious three-phase unbalance grid problem, each phase independently stable output 380V, precision ±1%~±2%
- Digital intelligent control system, faster response speed, higher stability than traditional servo regulator
- LCD digital display, real-time monitoring three-phase voltage, current, frequency and operating status
- High purity full copper coil winding, low heat generation, strong overload resistance, long service life
- Complete safety protection: overvoltage, undervoltage, overload, short circuit, phase loss protection
- Mobile caster design, flexible installation and movement in workshop
- No waveform distortion, no harmonic pollution, high efficiency ≥98%
Technical Parameters
| Item | Specification |
|---|---|
| Model | TNS-N-30KVA |
| Rated Capacity | 30KVA |
| Phase System | Three-phase four-wire |
| Rated Frequency | 50Hz |
| Input Voltage Range | 260V~430V |
| Rated Output Voltage | AC380V |
| Voltage Regulation Precision | ±1%~±2% |
| Regulation Method | Three-phase Separate Phase Digital Automatic Compensation Type |
| Response Time | ≤0.4s |
| Whole Machine Efficiency | ≥98% |
| Coil Material | High Purity Pure Copper |
| Protection Functions | Overvoltage, Undervoltage, Overload, Short Circuit, Phase Loss Protection |
| Working Mode | 24/7 Continuous Industrial Operation |
Application Scenarios
CNC machine tools, laser cutting equipment, injection molding machines, printing machinery, automated production lines, industrial workshops with serious three-phase unbalance power grid, laboratory precision instruments, central factory power distribution systems.
